The Ripsaw HD is a powerful spinner-tip nozzle designed to rotate at the perfect speed to increase digging power, improve control, and reduce wear and tear over time to lengthen its life. Built to battle the most extreme conditions – Ripsaw HD’s premium coating can take on frost, shale, and rocky soil, and is safe to operate around underground utilities.
The Ripsaw HD blasts a 0-degree straight water stream at up to 3200 PSI while rotating at a high speed to provide an 18-degree cone of coverage. The cone-shaped flow pattern is ideally suited for potholing applications.
The upgraded new heavy-duty coating is a special formulation designed for use in extreme environments including frost, shale, and other rocky conditions while protecting users and sensitive underground utilities.
APPLICATIONS:
Potholing, Daylighting, Debris Removal, Piling Hole, and Frac Tank Cleaning
FEATURES:
-
Non-Conductive Dupont Hytrel Coating – Safe for Work Around Underground Utilities
-
Tungsten Carbide Wear Surfaces – Longer Life than Ceramic Nozzles
-
Stainless Steel Housing – Withstands Harsh Environments
-
Rubber Boot – Provides Smooth Rotational Surface
-
Inlet Screen Block – Protects Against Contaminants
-
Max Water Temp – 180°F (+82°C)
SPECIFICATIONS:
Inlet (inch)
|
1/2" FNPT |
| Spray Angle (degree) |
18 |
| Flow Rates (gmp) |
1.5 - 10.7 |
| Max Pressure (psi) |
3200 |
| Inlet Pressure (psi) |
1000 - 3200 |
| Housing Material |
Stainless Steel |
| Coating Material |
Hytrel |
| Nozzle Tip Material |
Tungsten Carbide |
