Vivax

The vCam-6 HD inspection system from Vivax-Metrotech gives you the flexibility to cover a range of inspections including municipal collection systems, residential plumbing, indoor commercial lines. and lateral lines from three inches up to eight inches in diameter. Our camera systems use the latest technology packaged in a rugged, lightweight, compact profile made specifically for the harsh conditions related to sewer lateral inspections. All Vivax-Metrotech camera systems are backed by a full one-year warranty.

Increase productivity and profitability with the vCam-6 feature rich lateral and small mainline inspection camera system. Built tough and reliable for everyday use, the versatile vCam-6 is a good fit for plumbers, contractors, home inspectors, building maintenance supervisors, or anyone looking to inspect the interior of a pipe or duct. Create crisp, detailed HD video inspections with audio comments, text descriptions, footage, date, and timestamps to submit to your customers without worry. Putting in a full days' worth of work is easy with the four-hour battery life and charging on-the-go with the provided AC and DC charging leads. Includes monitor and reel.

The vCamMX-2 all-in-one mini inspection system gives you the flexibility to cover a range of inspections including indoor drain lines, residential plumbing, indoor commercial lines, and lateral lines up to four inches in diameter. The vCamMX-2 control module is designed and manufactured with the plumbing contractors' needs in mind. The latest technology in imaging and recording are packaged in a rugged ABS injection molded housing mounted to the stainless-steel frame is made specifically for harsh conditions.

The Type-MX reels are made of stainless steel tubular construction with a lightweight rugged carbon fiber pushrod drum. The multi angle LCD and frame which can be used in an upright or horizontal position is usable in tight confined space use, entering vents from rooftops stores easily in most utility vehicle compartments. The pushrod is traceable with the use of a utility locater transmitter and comes with a three frequency built-in locatable sonde.

The D-18 head is an 18mm non self-leveling head that can get you into pipes between an inch and a half to 4 inches of diameter. The D-26 head is a 26mm self-leveling High Definition head that allows you to get into 2-4 inch pipes. Both heads are stainless-steel housed with Sapphire lenses which makes them more resilient.

Two use interchangeable camera heads fit the Type-MX reel giving the user flexibility to handle lines from one and a half to four inches. The system is available in 100' & 150' lengths.

The VM-540 Sonde Locator comes standard with sonde/camera frequencies of 512Hz, 640Hz, and 33kHz, making it compatible with the major push cameras on the market. In addition to a visual peak bar graph that reaches its peak when over the sonde, a matching audible tone is heard which is loudest when over the sonde. The dot matrix display in the VM-540 shows a peak response in a bar graph with matching signal strength numbers, batter condition, speaker level, frequency setting and depth to the sonde with the puch of a button.

The VM-540 Sonde Locator is equipped with a "Passive" Power Mode which will detect the presence of power lines, and some metallic pipes which radiate 60Hz from nearby or overhead power lines.

Powered by two AA alkaline Batteries that typically provide 20 hours of use, the VM-540 is designed for reliable daily use.

The vLoc3-Cam is the easiest to use sonde locator on the market today. The omni-directional antenna array allows for approaching the sonde from any position. The directional arrows will guide the user first to the front or rear locate point and then directly to the sondes position.

The vLoc3-Cam includes multiple sonde frequencies making it compatible with the major push cameras and crawler cameras on the market. The Pushrod Trace mode shows a second display geared for tracing the path of the pushrod deployed in the pipe or tracing pipes with an optional portable transmitter.

The vLoc3-CAM comes with two passive locate modes of Power and Radio which will detect the presence of live power lines, CATV, telephone and some metallic pipes which radiate 50/60 Hz from nearby or overhead power lines. For active locating, with the use of a portable transmitter, the vLoc3-Cam comes with an 83.1kHz frequency for tracing the pushrod. This frequency is also ideal for water and gas utilities which generally are larger pipes with bell housings and gaskets as well as locating ungrounded small diameter drop wires and inducing signals through the soil, onto services when direct connection is not an option.

The Type "B" Skid is used to keep the camera head centered in pipes and off the floor avoiding debris and obstructions. The Type "B" Skid has adjustable settings for use in pipe diameters from 8" to 15". When the skid is completely collapsed it can be used in 8" pipes. the Type "B" Skid works with the D46 and D34 series camera attached to the 12mm termination spring on the Type-CP reel. This adjustable skid works best in straight run applications such as running from manhole to manhole.

The Rotate and Tilt Table (RATT) - mounts between the Type-CP reel and the vCam-5 control module. the RATT adds flexibility to position the control module to a comfortable viewing angle.

• Easy Installation
• Stainless-Steel Construction
• Locks the Control Module to the Reel
