ENZ Nozzles

The nozzle enz® KBRV is provided with 2 semi-radial jets directed forward in an angle of 45°. As a result, this nozzle must either be equipped with extra thrust jets or be mounted on a lance. The forward jets desintegrate most any residue and flush the debris ahead of the nozzle.

Applications

• To remove plastic deposits
• To clean heat exchangers
• Cleaning of fat deposits
• Flushing of the pipes from the house toward the main line

***Please leave a comment upon checkout noting the PSI and GPM required***

Nozzle Features a Rotating Jet for Total Cutting Performance.

Features:

• Rotating rear jet for flushing, debris removal and roots
• 4 - 12 GPM
• Up to 4,000 PSI
• Easily navigates traps and bends!
• Highly effective in 3" - 8" pipes
• Available in 1/4" and 3/8" sizes

***Please leave a comment upon checkout noting the PSI and GPM required***

The Chain scraper enz® is an apparatus which has many uses and is simple in handling and maintenance. Several different pipe diameters can be cleaned with the same tool. Layers of mineral deposits and concrete residues are efficiently removed.


Applications

• As preliminary operation before renovation with inliners, coatings or by injections
• Complete root removal
• Removal of incrustations and deposits
• Removal of concrete residues in newly installed sewage pipelines prior to inspection

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz®  cutting ball works without impact, but has the ability to switch in vibration. The cutting ball is equipped with a hard metal front cut for pipes that are more than 50% clogged. The side blades are self-sharpening and maintain their sharpness over their entire service life.

The cutting ball's area of application is diverse. Due to its spherical shape it goes easily around curves without damaging the pipe. The cutting ball is leakage-free and can be operated with recycling water.

Applications

• Interlaced roots
• Mineral deposits
• Lime scale

***Please leave a comment upon checkout noting the PSI and GPM required***

The semi-radial rotating enz®  nozzles with their 4 retroacting cutting-jets at an angle of approx. 45° cause simultaneously the cleaning procedure and the thrust for the forward move of the tool i.e. the jets combine rotation and thrust in one function resulting in a low water consumption. With sufficient water capacity, optional thrust jets can facilitate upward cleaning.

Applications

• Cleaning of pipes before TV-recordings
• To remove mineral deposits in pipes
• To remove roots up to Ø 0.2 inch

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum Ø 0.05 inch.

Transport and water costs are noticeably reduced.


Characteristics

• Easy to handle
• The tool is practically maintenance-free

 Applications

• To remove fat, roots and harder incrustations
• For operation with recycling water and fresh water

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum Ø 0.05 inch.

Transport and water costs are noticeably reduced.


Characteristics

• Easy to handle
• The tool is practically maintenance-free

 Applications

• To remove fat, roots and harder incrustations
• For operation with recycling water and fresh water

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum Ø 0.05 inch.

Transport and water costs are noticeably reduced.


Characteristics

• Easy to handle
• The tool is practically maintenance-free

 Applications

• To remove fat, roots and harder incrustations
• For operation with recycling water and fresh water

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum Ø 0.05 inch.

Transport and water costs are noticeably reduced.


Characteristics

• Easy to handle
• The tool is practically maintenance-free

 Applications

• To remove fat, roots and harder incrustations
• For operation with recycling water and fresh water

***Please leave a comment upon checkout noting the PSI and GPM required***

The enz® Bulldog® rotating nozzle has been designed for operation with recycling water and fresh water. The cleverly built sliding bearing allows the use of every kind of recycled water. An integrated oil-free braking system results in a low wear and tear operation and in controlled numbers of rotation. In this way a most efficient and economic pipe cleaning is achieved. The bore of the nozzle insert determines the admissible size of the dirt particles up to a maximum Ø 0.05 inch.

Transport and water costs are noticeably reduced.


Characteristics

• Easy to handle
• The tool is practically maintenance-free

 Applications

• To remove fat, roots and harder incrustations
• For operation with recycling water and fresh water

***Please leave a comment upon checkout noting the PSI and GPM required***

enz® nozzles with forward impact angle of approx. 45° on the pipe wall as well as a front jet (on request) and 3 retro-thrust jets cause a cork-screw-like advance through the clogged pipe. While the front nozzles loosens and the semi-radial nozzles disintegrate the residues, the thrust nozzles are driving the nozzle head forwards and simultaneously pushing the waste material backwards.

Applications

• Core-flushing of the steel pipes during hydraulic thrust-boring
• Cleaning of house connecting pipework from inside to the drain system
• Removal of ice in manholes

***Please leave a comment upon checkout noting the PSI and GPM required***
